FN022 - PIN and Key manager for FCA vehicles

FN022 - PIN and Key manager for FCA vehicles

€2.057,00
€2.057,00
Aanbieding Uitverkocht
Belastingen inbegrepen.
Alle details bekijken

This powerful license is dedicated to the PIN code reading and key and remote-control programming of Fiat/Lancia/Alfa/FCA (FIAT CHRYSLER AUTOMOBILES) vehicles for mechanical keys and keyless access keys.

License highlights:
Program keyless keys for the latest FCA vehicles, manufactured after 2020.

New models 2020+ added for key programming!

  • Alfa Romeo Guilia and Stelvio
  • Jeep Renegade, Wrangler, Gladiator
  • Fiat 500X
  • Dodge RAM (DT)
  • Fiat Qubo 2020+ and Fiorino 2020+
  • Maserati Levante and Ghibli
  • Fiat Tipo 2021 Keyless
  • Dodge Charger 2021 Keyless


Main functionalities:

  • PIN reading and Key programming
  • Transponders/Keys preparation
  • Remote control programming
  • BCM - Configuration data read and update PIN


In some vehicles, security gateway may be present, in which case the CB019 cable set is required to perform the procedure. In All Keys Lost situations, the CB017 and the ZN151 ABRITES Distribution Box is also required.
This license includes the functionalities of FN002, FN007, FN008, FN009, FN011, FN012, FN016, FN017 and CR005 legacy licenses.

An AVDI interface with an active AMS in order to purchase and ZN003 Protag programmer is needed to use this license.


Updates:

Update from FN020 to FN022

Free

Update from FN016 to FN022

€675.00 (Excl. VAT)

Update from FN019 to FN022

€225.00 (Excl. VAT)

Update from FN017 to FN022

€450.00 (Excl. VAT)

Update from FN018 to FN022

€375.00 (Excl. VAT)

Update from CR005 and FN016 to FN022

€750.00 (Excl. VAT)

Update from CR005 to FN022

€600.00 (Excl. VAT)

Key learning and remote programming by OBDII
ALFA ROMEO
147
159
Brera
Giulia
Giulietta
GT
Mito
Stelvio

FIAT
500
500L
500X
Albea
Argos
Bravo
Croma
Doblo
Ducato (HITAG2 mechanical keys, HITAGAES keyless keys)
Egea/ Egea keyless
Fiorino
Freemont
Grande Punto
Idea
Linea
Palio
Panda
Punto
Punto Evo
Qubo
Siena
Strada
Stilo
Tipo

LANCIA
Delta
Flavia
Thesis
Ypsilon

JEEP
Cherokee KL 2013+
Commander
Grand Cherokee (up to 2022)
Liberty (2008+)
Renegade (up to 2022)
Wrangler

CHRYSLER
200
300
Pacifica (2017+)
PT Cruiser
Sebring
Town & Country

DODGE
Aspen
Avenger
Caliber
Caravan
Challenger
Charger
Dart
Durango
Journey
Magnum
Neon
Nitro
RAM 1500, 2500, 3500, 4500, 5500
Viper (2013+)

RAM
Dakota
Promaster City
Promaster 1500, 2500, 3500 (up to 2019)
RAM 1500, 2500, 3500 Cab Chasis and Pickup, 4500, 5500
RAM (Mexico)

CITROËN
Jumper
Relay

IVECO
Daily (HITAG2 keys, HITAGAES keyless keys)

OPEL/VAUXHALL
Combo D
Movano C (2021+)

PEUGEOT
Boxer
Manager

Maserati
Ghibli
Levante
Quattroporte

FERRARI
612
FF
GTC4Lusso
Purosangue
599
F12
812
California
Portofino
Roma
458
488
F8
296
SF90

Transponder maker by dump - Preparing transponder by dump of BCM to be ready for key programing:

BCM Read/Update ConfData by OBDII from:
BCM Delphi (93C66) - NOTE: PIN Code is required!
BCM Delphi (NEC 70F3237/70F3379,93C86)
BCM Delphi (NEC 70F3556)
BCM Delphi (NEC 70F3557)
BCM Delphi (NEC 70F3632/70F3633) (up to 2020)
BCM Marelli (912DG128, 3K91D)
BCM Marelli (9S12DG256, 1K79X)
BCM Marelli (NEC 70F3237/70F3378,95160)
BCM Marelli (NEC 70F3633,95320)
BCM Marelli (MB91465P, 95640)
BCM Siemens (9S12DG128)

Fiat/Alfa/Lancia/FCA User Manual
View
